GMXB – LAB Micro

Completely self-contained and operator friendly, the GMXB-LAB Micro GRANUMEIST® Bottom Drive Bench Top High Shear Granulator/Mixer is ideally suited for today´s demanding process development requirements. Unlike other laboratory micro-scale mixers, the GMXB-LAB Micro is engineered with scalability in mind, utilizing product bowl and blade geometries that are consistent with Freund-Vector Corporation´s production GMXB systems and adjustable speed settings for matching mixer blade tip speeds. With a standard configuration that includes spare parts, one product bowl, solution addition capabilities, a 12 month warranty and quick delivery, the GMXB-LAB Micro represents the best equipment value in its class.

For Developmental High Shear Wet Granulation and Mixing Processes

Maximum Process Flexibility

Interchangeable Product Bowls: 1L, 2L, 4L and 6L
User-Defined Settings for Mixer and Chopper Blade Speeds
Integrated Peristaltic Pump
Rated For Solvent Operation
Optional Jacketed Bowl

Bottom Drive, Self-Contained System

Quick Change Design – No Tools Required For Cleaning or Changeover

Engineered Scalability

Consistent With Production GMXB Systems
- Proportional Mixer Blade Tip Speeds
- Bowl and Blade Geometries

Color Touchscreen Control System

Configured For Easy Operation

Validatable Process Control

Multiple End Point Detection Parameters

Mixer Power – With Trending Screen
Granulation Time
Product Temperature

GMXB – LAB Micro

GRANUMEIST® Bottom Drive Bench Top High Shear Granulator/Mixer

TECHNICAL SPECIFICATIONS

TECHNICAL SPECIFICATIONS
Design Standards：CE, UL, NFPA, CSA		Electrical Supply：230VAC/1 Phase/50-60Hz
Safety Standards：Class 1 Div.2 and ATEX Zone 2		Weight：127 kg(Floating)
BOWL SPECIFICATIONS
Bowl Capacity	1.0 L	2.0 L	4.0 L	6.0 L
Working Capacity	0.3 - 0.7 L	0.6 - 1.4 L	1.2 - 2.8 L	1.8 - 4.2 L
Mixer Speed	710 - 1100 RPM	640 - 990 RPM	525 - 820 RPM	455 - 710 RPM
Chopper Speed	300/3000 RPM	300/3000 RPM	300/3000 RPM	300/3000 RPM
